Features
- Ideal for packaging, material handling and air motor applications.
- Ideal for double acting pneumatic cylinders
- Compact size with excellent flow capacity
- Single and double solenoid or pilot models
- Three voltages available 120 VAC, 12 and 24 VDC
- Lightweight aluminum bodies and Buna-N seals are standard
- Manifold mounting available, blanking plates available for future expansion.
- Max/Air valves use Alpha style 22mm coil
- 1/4″ = 26 mm body size
- 3/8″ = 30 mm body size
- 1/2″ = 34 mm body size
- 3-position spool function provides wider application flexibility: MaxAir offers 3-position spool configuration with all ports blocked in center.
- Solenoid coils and connectors provide quick, clean connections: Coils are Class F rated for 100% duty cycle applications at 122° F (50° C). AC or DC coils can be interchanged on the same solenoid stem. Each solenoid connector acts as its own junction box, with molded connectors and gaskets to protect electrical connections. Design meets NEMA-4 classifications.
- One-touch manual override (standard): MaxAir contains a mechanical valve override that can be adjusted to a locking (push and twist) position or non-locking function.
- Valves are body-threaded and can be manifold-mounted: MaxAir is a body-threaded valve that can be directly plumbed or manifold-mounted, where there is a need for multiple valves in tight spots, especially in machine design operations. Manifolds available in 2, 4, 6, 8, 10, and 12 station configurations.
